Specification

• Product Size: 138x16x17mm
• Instrukcja dla modelu
• "1. Direct Test.
• 2.Induction Break-point Test"
• Check AC Voltage - Touch the metal tip of the tester to the test point. Touch the ① or ② button with your finger: (This product is only used for ordinary high voltage and low voltage detection. The data is not a standard value.)
• "AC checking: touch the detection button ① Use a pen to measure the test site voltage, if the voltage number string is displayed, it is a live wire (LCD display ""12V36V55V"" means voltage is equal or lower than 55V, and display "" ""12V36V55V110V220V"" ""means the voltage range is 55V-220V), only if 12V or 12V36V is displayed, it is neutral line or ground line.
• Note: If the ground wire or the neutral wire is disconnected, the voltage on the live wire may be felt on the ground wire or the neutral wire. During this time, a very high voltage is displayed and an electrician repair is required."
• "Breakpoint Check - Press and hold the sensor test button ② with your finger, and move the metal tip along the outside of the wire. The display symbol ⚡ indicates the presence of voltage on the wire.
• If the ⚡ symbol disappears at a certain point, that point is the cable break."
• Direct current inspection: measuring direct current is only suitable for electrician professionals, the scope of application is 12-36V, the display ⚡ means there is electricity, and no display means no electricity.
• Attention!
• When using the tester, observe the general rules and regulations of occupational health and safety relating to work with installations and devices with a supply voltage of up to 250V, which will allow you to safely carry out the tests described above.
• Children under the age of 8 and those without relevant knowledge are prohibited from using this product.
